| Ogólne | |
| Wymiary | 438mm x 40mm x 172mm - montaż w racku 19" (1U) |
| Wejścia |
DVI-D (Dual-Link)
USB (Typ B)
IEC
|
| Wyjścia | 8 x DVI-D (Dual-Link) |
| Panel przedni |
Przyciski nawigujące
Trzy diody LED (Zasilanie/ Wejście/ Status)
|
| USB |
USB 2.0 dla konfiguracji urządzenia
Współpracuje z systemami operacyjnymi: Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008, Windows 7
|
| Capabilities | |
| Input Capabilities |
Incorporates TMDS re-clocking equaliser to support up to 20m cables
Programmable EDID to indicate preferred mode
No limit to aspect ratios or frame rates of DVI signals that can be accepted, provided they remain within the Dual-Link 330MHz specification
Input is not HDCP compatible
|
| Output Capabilities | Supports up to 5m cables into standard DVI receiver¹ |
| Other | |
| Power Requirements | Universal power supply (100-240V) 25W maximum |
| Temperature |
Operating temperature: 0 to 35 °C (32 to 96 °F), internal fan cooling
Storage temperature: -20 to 70 °C (-4 to 158 °F)
|
| Relative Humidity | 5% to 90% non-condensing |
| Warranty | 3 years |
¹ Output cable lengths can be extended when driving receivers with built in equalisation - up to 20m for Datapath x4
We are continously developing the technology used within our product ranges delivering outstanding innovative solutions, therefore the specification may change from time to time.
