22 648 04 07
| Board format | 4 lane PCI Express |
| Card size | 110mm x 170mm |
| Maximum capture resolution | 8 x 720 x 576 x 16bit |
| Maximum number of cards per system | 16 (128 video capture channels) |
| Frame buffer memory | 32MB |
| Maximum current at +3.3V | 0.25A |
| Maximum current at +12V | 0.6A |
| Maximum power | 8 watts |
| Operating temperature | 0 to 35 deg C |
| Storage temperature | -20 to 70 deg C |
| Relative humidity | 5% to 90% non-condensing |
| MTBF | 100,000 hrs |
